| Place of Origin: | China |
|---|---|
| Certification: | CE |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Carton |
| Delivery Time: | Peak Season Lead Time: within 15 workdays Off Season Lead Time: within 15 workdays |
| Payment Terms: | T/T, PayPal |
| Supply Ability: | 5000 |
| Model NO.: | GM69 | Operating Current: | 180mA |
|---|---|---|---|
| Interface: | USB/Uart | Resolution: | 1d>=4mil, 2D>=7.54mil |
| Size: | 54.8(W)*31.5(D)*13(H)mm | Scan Mode: | 1280*800 CMOS |
| Standby Current: | USB:25mA; Ttl:10mA | Transport Package: | Standard Export Carton Package |
| Specification: | Black | Trademark: | GROW |
| Origin: | China | HS Code: | 8473309000 |
| Supply Ability: | 5000 | Interface Type: | Uart, USB |
| Scan Element Type: | CMOS | Operating Voltage: | 5V |
| Samples: | US$ 46/Piece 1 Piece(Min.Order) | | Customization: | Available | Customized Request |
| Shipping Cost: | About Shipping Cost And Estimated Delivery Time. | Payment Method: | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Scanning Performance |
Scan Mode | 1280*800 CMOS | ||
| Lighting | White LED | |||
| Collimate | Red LED | |||
| Read Code Type |
2D | QR Code, Data Matrix, PDF417,Aztec,Micro QR, Micro PDF417,Maxicode,Hanxin Code |
||
| 1D |
EAN,UPC,Code 39,Code 93,Code 128,UCC/EAN 128, Codabar, | |||
| Interleaved 2 of 5, ITF-6,ITF-14,ISBN,ISSN, MSI-Plessey | ||||
| GS1 Databar ,Code 11,Industrial 25,GS1 Composite | ||||
| Standard 25,Plessey, Matrix 2 of 5 | ||||
| Accuracy of reading | 1D≥4mil , 2D≥7.54mil | |||
| Depth of Field |
EAN-13 | 35mm-220mm (13mil 13byte) | |
|
| Code 39 | 30mm-135mm (5mil 4 byte) | |||
| QR Code | 45mm-460mm (20mil 16 byte) | |||
| Data Marix | 25mm-180mm (10mil 20 byte) | |||
| PDF417 | 30mm-160mm (6.67mil 7 byte) | |||
| Contrast | ≥25% | |||
| Scanning angle | Intersection angle 360°,Elevation ± 55° Deflection angle ± 55° |
|||
| Viewing Angle | H:52° V:38° | |||
| Mechanical/ Electrical Parameters |
Interface | TTL-232 , USB (HID-KBW, Virtual serial port) | ||
| Dimension | 54.8(W)*31.5(D)*13(H)mm | |||
| Operating Voltage | DC 5 V | |||
| Operating Current | 180mA | |||
| Standby Current | USB:25mA; TTL:10mA | |||
| Environmental Parameters | Operating Temperature | -20ºC~+50ºC | ||
| Storage Temperature | -40ºC~+70ºC | |||
| Operating Humidity | 5%~95%(Non-Condensing) | |||
| Environmental Light | 0~100000LUX | |||
