| Place of Origin: | China |
|---|---|
| Certification: | CE |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Carton |
| Delivery Time: | Peak Season Lead Time: within 15 workdays Off Season Lead Time: within 15 workdays |
| Payment Terms: | T/T, PayPal |
| Supply Ability: | 5000 |
| Model NO.: | GM77 | Operating Current: | 180mA |
|---|---|---|---|
| Reading Distance: | 25 - 250mm | Interface: | USB/Uart |
| Resolution: | 0.10mm (4mil) | Transport Package: | Standard Export Carton Package |
| Specification: | Black | Trademark: | GROW |
| Origin: | China | HS Code: | 8473309000 |
| Supply Ability: | 5000 | Package Size: | 13.00cm * 8.00cm * 9.00cm |
| Package Gross Weight: | 0.200kg | Interface Type: | Uart, USB |
| Scan Element Type: | CMOS | Operating Voltage: | 5V |
| Samples: | US$ 22/Piece 1 Piece(Min.Order) | | Customization: | Available | Customized Request |
| Shipping Cost: | About Shipping Cost And Estimated Delivery Time. | Payment Method: | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
|
Scanning Performance
|
Scan Mode
|
640*480 CMOS
|
||
|
Lighting
|
White LED
|
|||
|
Collimate
|
Red LED
|
|||
|
Read Code
Type |
2D
|
QR Code, Data Matrix, PDF417,Aztec,Micro QR,Micro PDF417
|
||
|
1D
|
EAN,UPC,Code 39,Code 93,Code 128,UCC/EAN 128, Codabar,
|
|||
|
Interleaved 2 of 5, ITF-6,ITF-14,ISBN,ISSN, MSI-Plessey
|
||||
|
GS1 Databar ,Code 11,Industrial 25,
|
||||
|
Standard 25,Plessey, Matrix 2 of 5
|
||||
|
Accuracy of reading
|
≥4mil
|
|||
|
Depth of Field
|
EAN-13
|
50mm-220mm (13mil)
|
|
|
|
Code 39
|
40mm-90mm (5mil 10 byte)
|
|||
|
QR Code
|
25mm-200mm (20mil 16 byte)
|
|||
|
Data Marix
|
50mm-90mm (10mil 20 byte)
|
|||
|
PDF417
|
30mm-130mm (6.67mil 7 byte)
|
|||
|
Contrast
|
≥25%
|
|||
|
Scanning angle
|
Intersection angle 360°,Elevation ± 55°
Deflection angle ± 55° |
|||
|
Viewing Angle
|
Horizontal:47°Vertical:36°
|
|||
|
Mechanical/
Electrical Parameters |
Interface
|
TTL-232 , USB (HID-KBW, Virtual serial port)
|
||
|
Dimension
|
27.5(W)*48.5(D)*14(H)mm
|
|||
|
Operating Voltage
|
DC 5 V
|
|||
|
Operating Current
|
180mA
|
|||
|
Standby Current
|
USB:50mA; TTL:10mA
|
|||
|
Environmental Parameters
|
Operating Temperature
|
-20ºC~+50ºC
|
||
|
Storage Temperature
|
-40ºC~+70ºC
|
|||
|
Operating Humidity
|
5%~95%(Non-Condensing)
|
|||
|
Environmental Light
|
0~100000LUX
|
|||
